Description
The Mimaki TxF300-75 is a high-production, dual-head direct-to-film printer designed for Canadian apparel decorators ready to scale. Delivering speeds up to 300% faster than the TxF150 model, this 31.5-inch unit features advanced white ink circulation technology to ensure consistent, clog-free operation for high-volume custom t-shirt and sportswear runs.
Triple the Speed. Industrial Reliability.
Meet the demand for fast-turnaround custom apparel without compromising on stability. The Mimaki TxF300-75 builds on the success of the TxF150 by integrating a second print head, effectively tripling productivity. This increase in speed allows print shops to handle larger bulk orders of transfers in-house, reducing the need to outsource during peak seasons.
Designed for professional DTF workflows, this machine prints directly onto film using Mimaki’s specialized heat transfer pigment inks. The result is a versatile transfer that adheres to cotton, polyester, nylon, and blends—materials that traditional direct-to-garment (DTG) printers often struggle with
.
Further protecting your investment, the degassed ink pack design prevents air from entering the ink path, a common cause of poor ejection in other systems.
Key Features
-
Dual Print Heads: Two staggered heads deliver production speeds up to 3 times faster than the entry-level TxF150-75
.
-
Degassed Ink Packs: Aluminum ink packs reduce oxygen intrusion, ensuring stable ink ejection and reducing waste
.
-
OEKO-TEX® Certified: Uses PHT50 inks which have achieved ECO PASSPORT certification, meeting safety standards for textile chemicals
Why Choose the TxF300-75?
For Canadian print shops, the TxF300-75 represents a safe, reliable step up into high-volume manufacturing. By choosing a brand-name solution over modified/converted printers, you gain access to a dedicated support network and parts availability. This machine is engineered specifically for the physics of transfer film, providing the consistency needed to grow your business.
Specifications
| Feature | Details |
| Printhead | Dual On-demand piezo heads |
| Print Resolution | 720 dpi, 1,440 dpi |
| Maximum Print Width | 31.5″ (800 mm) |
| Maximum Media Width | 31.9″ (810 mm) |
| Maximum Media Thickness | Up to 0.04″ (1 mm) |
| Maximum Media Weight | Up to 99.2 lbs (45 kg) |
| Ink Type | Heat transfer pigment ink PHT50 (C, M, Y, K, W) |
| Interface | Ethernet 1000 BASE-T / USB 2.0 |
| Power Supply | Single-phase AC 100-120 / 200-240V ±10%, 50/60Hz ±1Hz |
| Power Consumption |
100V system: 1.44 kW 200V system: 1.92 kW |
| Operational Environment |
Temperature: 68°F – 86°F (20°C – 30°C) Humidity: 35% – 65% RH (Non-condensing) |
| Dimensions (W × D × H) |
77.4″ x 27.6″ x 54.8″ (1,965 mm × 700 mm × 1,392 mm) |
| Weight | 277.8 lbs (126 kg) |
| Certifications | VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, KC |
